This is a retrofit "flashing kit for penetrating the tent and slanting chimney" for bringing a camping wood stove into the tent and using it.
Since it comes with an off-season rain cap, the through hole can be covered with a cap during the season when the stove is not used, so even a tent for a wood stove can be used in the same way as a normal tent.
This item will be shipped free of charge. Since the shipping method is letter pack plus, etc., it will be folded and shipped.
● Set contents: Silicon flashing, two aluminum plates (ring-shaped), stainless steel bolts and wing nuts, off-season rain cap, installation manual with photos
# Color: Chocolate Brown
# Frame size: Oval shape with vertical 31 cm x horizontal 22 cm, height is about 13 cm
＃The heat resistance temperature of silicon is about 300℃.
＃The rain cap is made of stainless steel with a thickness of 0.5 mm.
# Corresponding chimney diameter: about 45mm to 106mm
When installing to the tent, it is necessary to prepare a Phillips screwdriver, a lighter, a gas burner, etc. (to heat the tip of the screwdriver or peg to make a hole), a cutter knife, scissors, etc.
The flushing has a 45mm diameter hole in advance, so when using a chimney with a larger size, cut it with scissors before use.
*Although a 120mm chimney can fit in, this is not recommended.
Installation time is about 15 to 30 minutes. Two people are recommended, but it can be installed by one person.
Even when the temperature of the chimney is around 200℃, the silicon part (at the point closest to the chimney) only rises to about 120℃, so there is no problem even if the silicon part and the chimney are in direct contact.
This kit allows you to bring your stove into any tent.
By bringing the stove into the tent, the inside of the tent becomes very warm, so it is recommended for those who camp in autumn, winter and spring.
※※Please refrain from using the wood stove at bedtime as it is dangerous.
Have a nice stove life!
